BEA 71/16-421S - Technical Data; Safety Advices

EN - 12
Device-specific additional instructions for nailer 71/16 - 421S
1 Technical data
71/16-421S
Actuation modes:
Contact
actuation
Depth adjustment: No
Height/ length (mm): 148 / 221 Weight (without fasteners)(kg): 0,97
Min/max operating pressure
(bar):
4 - 6 Air consumption per driving operation: 0,3 l at 6 bar
Noise characteristics (according to EN12549:1999):
L
pA
,
1s
L
WA
,
1s
K pA and K WA
77,8 dB(A) 84 dB(A) 2,5 dB(A)
Vibration value (according to ISO 28927-13:2022-02):
a
hd
K
a
1,02 m/s² 0,6 m/s²
Fasteners
Staple 71
Length (mm): 6 - 16
Wire diameter (mm): 0,55 x 0,75
Crown width (mm): 9
Scope of delivery Pneumatic nailer, General operating instructions, device-specific information
2 Safety advices
Risk of most severe injuries from nailers!
Any person operating the nailer must have read and understood both the following device-specific information as
well as the General operation instructions for pneumatic nailers! Always have both documents ready!
Operating the device without knowing the General operating instructions is forbidden!
Resulting problems extinct any possible claims against the manufacturer.
3 Safe resting position
 Whenever not in use, safely put down the device
on its left or right side according to adjacent symbol
picture (see Chap. 1.3 of General operating instructions).
 Do not put down the device on another side.
 Also when putting down or lifting up, never point the driving
nose at persons or animals.
F
front
B
back
L
left
R
right
T
top
U
underside
