BEA DC/130-1302E - Technical Data; Safety Advices

EN - 6
Device-specific additional instructions for nailer 1302 E
1 Technical data
DC/130-1302E
Actuation modes:
Single
sequential
actuation
Depth adjustment: No
Height/ length (mm): 489 / 356 Weight (without fasteners)(kg): 6,6
Min/max operating pressure
(bar):
5 - 8 Air consumption per driving operation: 4 l at 6 bar
Noise characteristics (according to EN12549:1999):
L
pA
,
1s
L
WA
,
1s
K pA and K WA
92,4 dB(A) 101,1 dB(A) 2,5 dB(A)
Vibration value (according to ISO 8662-11:1999):
a
hd
K
a
3,99 m/s² 1,18 m/s²
Fasteners
Wire coil nail
Length (mm): 90 - 130
Wire diameter (mm): 3,3-3,8
Scope of delivery Pneumatic nailer, General operating instructions, device-specific information
2 Safety advices
Risk of most severe injuries from nailers!
Any person operating the nailer must have read and understood both the following device-specific information as
well as the General operation instructions for pneumatic nailers! Always have both documents ready!
Operating the device without knowing the General operating instructions is forbidden!
Resulting problems extinct any possible claims against the manufacturer.
3 Safe resting position
• Whenever not in use, safely put down the device
on its left or right side according to adjacent symbol
picture (see Chap. 1.3 of General operating instructions).
• Do not put down the device on another side.
• Also when putting down or lifting up, never point the driving
nose at persons or animals.
F
front
B
back
L
left
R
right
T
top
U
underside
