BEAMEX PGM - Page 4

F i n e c o n t r o l
C o n n e c t o r s
f o r p r e s s u r e
m e a s u r e m e n t
h o s e s
M a i n p i s t o n h a n d l e s
R e l e a s e v a l v e
Screw for fastening
the cylinder block
Cylinder collar
1.5 mm hex screw
Fine control seal
Release valve seal
Check valve seal
Main piston lock ring
2.0 mm hex screw
Release valve stemRelease valve hand wheel
Main piston
NOTE! Using PGM with seals not supplied by Beamex is at your own
risk. The warranty is no longer valid when using other seals
than the ones supplied by Beamex.
