Beamz COB50 - Page 26

26
MENU / MENÜ / MENÚ
Mode Description
A001~A511 A001~A511 DMX adres
Au** Au 1 ~Au31 Preset colours 1~31
FF** FF 1~FF99 Jump variable, The last two figure more big, the colour change speed will more fast
CC** CC 1~CC99 Gradual variable, The last two figure more big, the colour change speed will more fast
EE** EE 1~EE99 Pulse variable, The last two figure more big, the colour change speed will more fast
F*** F001~F009 No strobe
F010~F255 Strobe from slow to fast
AuTo Auto Auto mode, Repeat play FF**, CC**, EE**, F***
Soud Soud Sound mode
bLOF/bLON Press ENTER button, “BL”flicker, “OF” means without sound activated but not shut off,
“ON”without sound activated black out
VOL1~Vol9 Press ENTER button, “VOL”flicker, “1~9”Means sound sensitivity, the value more bis,
sensitivity more high
DMX CHANNELS / DMX KANALEN / DMX-KANÄLE / CANALES DMX /
CANAUX DMX / KANAŁY DMX / DMX KANÁLY
Channel Function
V
alue Descri
p
tion
1 Dimming 000-255 Master dimming
2
Red
000-255
Red 0-100%
3
Green
000-255
Green 0-100%
4
Blue
000-255
Blue 0-100%
5
White
000-255
White 0-100%
6
Amber
000-255
Amber 0-100%
7
Strobe
000-009
No strobe
010-255
Strobe from slow to fast
8
Auto/Sound
000-050
Manual mode, the first 7 channel are effective
051-100
Jump variable, The last two figure more big, the colour change
101-150
Gradual variable, The last two figure more big, the colour change
151-200
Pulse variable, The last two figure more big, the colour change
201-250
Auto mode, The last two figure more big, the colour change speed
251-255
Sound mode, The last two figure more big, the colour change
9
Speed
000-255
Adjust speed, only have effective to CH8
TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Rated voltage : AC100～240V 50/60Hz
Rated power : 65W
LED : RGBWA 5-in-1
DMX Channels : 9 Channels
Function : DMX, Auto, Sound active and Master-Slave.
Dimensions per unit : 200 x 170 x 191mm
Weight (per unit) : 1.1 kg
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
