Beamz LCB144 - DMX Channel Assignments; 3, 5, and 6 Channel Modes

27
MENU / MENÜ / MENÚ
Mode Programming Description
Add
r
001-512 Dmx address setting
Chnd
3 Channels
Setting DMX channel mode
5 Channels
6 Channels
12 Channels
24 Channels
48 Channels
Slnd
Mast Master setting
Sl1 Slave 1
Sl2 Slave 2
D512 When no DM
X
signal is received, no function: Blackout
Soun
So0
–
So16 Sound controlled mode
Se00 -Se99 Microphone sensitivity (increasing)
Auto
Au1 – Au16 Auto mode
Sp0 – Sp9 Speed increasing
Colo
Red 000
–
255
0 – 100%
Green 000 - 255
Blue 000 - 255
Disp
Disp
Display reverse 180
Dsip
Ve
r
Software version
Rset Reset
DMX CHANNELS / DMX KANALEN / DMX-KANÄLE / CANALES DMX /
CANAUX DMX
3 Channels
Channel Function
V
alue Descri
p
tion
1
Colour
000-255 0-100% Red
2 000-255
0-100% Green
3 000-255
0-100% Blue
5 channels
Channel Function
V
alue Descri
p
tion
1
Colour
000-255 0-100% Red
2 000-255
0-100% Green
3 000-255
0-100% Blue
4 Master dimmer 000-255 Dimmer all LED’s 0-100%
5 Sound/Strobe
000-255 No function
001-005 Sound control (7color)
006-010 No function
011-255 Strobe with increasing speed
6 channels
Channel Function
V
alue Descri
p
tion
1 Master dimmer 000-255 Dimmer all LED’s 0-100%
2
Strobe
000-255
Strobe (Fast to slow)
3
Colour
000-255 0-100% Red
4 000-255
0-100% Green
5 000-255
0-100% Blue
6
Auto
000-015
No function
016-255
Auto program (Fast to slow)
