Beamz LCB144 - DMX Channel Assignments (Extended); 12 and 24 Channel Modes

28
12 channels
Channel Function
V
alue Descri
p
tion
1 Master dimmer
Section
1
000-255 Dimmer all LED’s (1+2+3+4) 0-100%
2
Strobe
000-255
Strobe (Fast to slow)
3
Colour
000-255 0-100% 1+2+3+4 Red
4 000-255
0-100% 1+2+3+4 Green
5 000-255
0-100% 1+2+3+4 Blue
6
Auto
000-255
Auto program (Fast to slow)
7
Master dimmer
Section
2
000-255 Dimmer all LED’s (5+6+7+8) 0-100%
8
Strobe
000-255
Strobe (Fast to slow)
9
Colour
000-255
0-100% 5+6+7+8 Red
10 000-255
0-100% 5+6+7+8 Green
11 000-255
0-100% 5+6+7+8 Blue
12
Auto
000-255
Auto program (Fast to slow)
24 Channels
Channel Function
V
alue Descri
p
tion
1
Colour
Section 1
000-255 0-100% Red
2 000-255
0-100% Green
3 000-255
0-100% Blue
4
Colour
Section 2
000-255 0-100% Red
5 000-255
0-100% Green
6 000-255
0-100% Blue
7
Colour
Section 3
000-255 0-100% Red
8 000-255
0-100% Green
9 000-255
0-100% Blue
10
Colour
Section 4
000-255 0-100% Red
11 000-255
0-100% Green
12 000-255
0-100% Blue
13
Colour
Section 5
000-255 0-100% Red
14 000-255
0-100% Green
15 000-255
0-100% Blue
16
Colour
Section 6
000-255 0-100% Red
17 000-255
0-100% Green
18 000-255
0-100% Blue
19
Colour
Section 7
000-255 0-100% Red
20 000-255
0-100% Green
21 000-255
0-100% Blue
22
Colour
Section 8
000-255 0-100% Red
23 000-255
0-100% Green
24 000-255
0-100% Blue
