Beamz LCB224 - Page 30

1
Master dimmer
000-255
Dimmer, 0-100%
2
Colour
000-255
LED Red, 0-100%
3
000-255
LED Green, 0-100%
4
000-255
LED Blue, 0-100%
5
Mode
000-009
No function (CH2-Ch4is valid)
010-013
Static colour (CH7 selection)
014-017
Program show 1
018-021
Program show 2
…..
…..
226-229
Program show 54
230-233
Auto Mode（run program show 1-54）
234-237
DMX Sound mode1
238-241
DMX Sound mode2
242-255
DMX Sound mode3
6
000-009
No function (CH5 is valid)
Sections
Control the colours with
CH2, CH3 and CH4
CH7 value 100 will switch
off the other Sections
010-015
Section 1, LEDs are on
016-021
Section 2, LEDs are on
022-027
Section 3, LEDs are on
028-033
Section 4, LEDs are on
034-039
Section 5, LEDs are on
040-045
Section 6, LEDs are on
046-051
Section 7, LEDs are on
052-057
Section 8, LEDs are on
058-063
Section 9, LEDs are on
064-069
Section 10, LEDs are on
070-075
Section 11, LEDs are on
076-081
Section 12, LEDs are on
082-087
Section 13, LEDs are on
088-093
Section 14, LEDs are on
094-099
Section 15, LEDs are on
100-105
Section 16, LEDs are on
Pattern
Control the colours with
CH2, CH3 and CH4
106-111
Pattern effect 1
112-117
Pattern effect 2
…..
…..
244-255
Pattern effect 24
7
Speed
000-255
DMX Program Speed(Slow->fast)
Static colour
(If CH5 value 010-013)
000-009
No function
010-019
Static colour 1
020-029
Static colour 2
…..
…..
250-255
Static colour 25
8
Strobe
000-009
No function
010-255
Strobe, slow to fast
