1
Master dimmer
000-255
Dimmer, 0-100%
2
Colour
000-255
LED Red, 0-100%
3
000-255
LED Green, 0-100%
4
000-255
LED Blue, 0-100%
5
Mode
000-009
No function (CH2-Ch4 is valid)
010-013
Static colour (CH7 selection)
014-017
Program show 1
018-021
Program show 2
…..
…..
226-229
Program show 54
230-233
Auto Mode（run program show 1-54）
234-237
DMX Sound mode1
238-241
DMX Sound mode2
242-255
DMX Sound mode3
6
Pattern
Control the colours with
CH2, CH3 and CH4
000-009
No function (CH5 is valid)
010-019
Pattern effect 1
020-029
Pattern effect 2
…..
…..
244-255
Pattern effect 24
7
Speed
000-255
DMX Program Speed (Slow->fast)
Static colour
(If CH5 value 010-013)
000-009
No function
010-019
Static colour 1
020-029
Static colour 2
…..
…..
250-255
Static colour 25
8
Strobe
000-009
No function
010-255
Strobe, slow to fast
9
Section dimmer
(If CH5 & CH6 value 000-
009)
000-255
Section 1, dimmer 0-100%
10
000-255
Section 2, dimmer 0-100%
11
000-255
Section 3, dimmer 0-100%
12
000-255
Section 4, dimmer 0-100%
13
000-255
Section 5, dimmer 0-100%
14
000-255
Section 6, dimmer 0-100%
15
000-255
Section 7, dimmer 0-100%
16
000-255
Section 8, dimmer 0-100%
17
000-255
Section 9, dimmer 0-100%
18
000-255
Section 10, dimmer 0-100%
19
000-255
Section 11, dimmer 0-100%
20
000-255
Section 12, dimmer 0-100%
21
000-255
Section 13, dimmer 0-100%
22
000-255
Section 14, dimmer 0-100%
23
000-255
Section 15, dimmer 0-100%
24
000-255
Section 16, dimmer 0-100%
