24
1. Place the outdoor unit on the support.
2. Fix the foot holes of the outdoor unit
with bolts.
Step four: connect indoor and
outdoor pipes
1. Remove the screw on the right
hand side of the outdoor unit
and then remove the handle.
2. Remove the screw cap from the valve
and aim the pipe joint at the pipe’s
bell mouth.
3. Pre-tightening the union nut by hand.
Foot holes
Foot holes
Screw
Handle
Gas pipe
Gas valve
Pipe joint
Union nut
