Split Air Conditioner | Aire Acondicionado Split | Ar Condicionado Split
4. Adding refrigerant oil and refrigerant after extending pipe
connections
If the connection pipe is extended by 10 m beyond its standard
length, you must add 5 ml of refrigerant oil for each additional 5 m of
connection pipe.
Calculating the additional refrigerant (liquid pipe):
(1) Amount of additional refrigerant = additional (extended) length
of liquid pipe* additional amount of refrigerant per meter
(2) Based on the length of the standard pipe, add refrigerant
according to the requirement in the table below. The amount of
additional refrigerant per meter varies with the diameter of the
liquid pipe. See Sheet 2.
Table 3. Additional R32 refrigerant
Note: The amount of additional refrigerant in Sheet 2 is a recommended
value, and not compulsory.
Diameter of connection
pipe mm
Indoor unit
throttle
Outdoor unit throttle
Liquid pipe Gas pipe
Cooling
only, cooling
and heating
(g / m)
Cooling only
(g / m)
Cooling
and heating
(g / m)
Ø6 Ø9.5 or Ø12 16 12 16
Ø6 or Ø9.5 Ø16 or Ø19 40 12 40
Ø12
Ø19 or
Ø22.2
80 24 96
Ø16
Ø25.4 or
Ø31.8
136 48 96
Ø19 _ 200 200 200
Ø22.2 _ 280 280 280
