Becker a100/25 - Technical Data

1
Technical data
Type Unit A100
Output torque T Nm 100
Output speed n min
-1
25
Diameter of hollow shaft mm 25.4
Operating voltage U V 3~230 / 400
Frequency F Hz 50
Nominal current I A 4.6/2.6
Power factor Cos 0.64
Cycles
*2)
1/h 6
Insulation material class H
Thermoswitch °C 170
Degree of protection IP 54
Limit switch range Revolutions 13
Static holding torque Nm 450
On-site fuse protection 3x10AT
Permissible ambient operating
temperature
°C -20 to +40
Emission sound pressure level dB(A) ≤ 70
Weight
*1)
(approx.) kg 10
*1)
) With the LK version, the weight increases by approx. 0.5 kg.
*2
) A cycle is an opening and closing over the entire limit switch range at the full output torque as specified in the technical data.
The actual door cycles depend on the design, e.g. size and weight of the door.
Deviations are possible in structurally identical drives or special drives.
The information on the type plate always applies.
Subject to technical changes without notice.
