Becker VT 4.40 - PRODUCT DATA SHEET; OPERATING PARAMETERS

31 | VT 4.10, VT 4.16, VT 4.25, VT 4.40, VX 4.10, VX 4.16, VX 4.25, VX 4.40
9 PRODUCT DATA SHEET
9.1 PRODUCT OVERVIEW
Example: VT 4.40
9.2 OPERATING PARAMETERS
Variant
VT 4.10
VT 4.16
VT 4.25
VT 4.40
Volume flow min.
10 m³/h (50 Hz)
16 m³/h (50 Hz)
25 m³/h (50 Hz)
40 m³/h (50 Hz)
Volume flow max.
12 m³/h (60 Hz)
19 m³/h (60 Hz)
30 m³/h (60 Hz)
48 m³/h (60 Hz)
Vacuum
150 mbar (abs)
150 mbar (abs)
150 mbar (abs)
150 mbar (abs)
Weight
16 kg
22,5 kg
26 - 29 kg
38 - 41 kg
Sound level min.
60 dB(A) (50 Hz)
61 dB(A) (50 Hz)
62 dB(A) (50 Hz)
67 dB(A) (50 Hz)
Sound level max.
62 dB(A) (60 Hz)
64 dB(A) (60 Hz)
67 dB(A) (60 Hz)
72 dB(A) (60 Hz)
Permissible ambient
temperature
5 - 45 °C
5 - 45 °C
5 - 45 °C
5 - 45 °C
Exhaust air temperature max.
87 °C
93 °C
118 °C
126 °C
Maximum installation height
800 m ü.NN.
800 m ü.NN.
800 m ü.NN.
800 m ü.NN.
Maximum humidity of the
intake air
90 %
90 %
90 %
90 %
Table 9.2: Operating parameters
