Assembly and connecting
CX9000 / CX901036 Version: 2.6
Then fix the CX90x0 block on the top hat-rail using the latching straps. You should hear a soft click.
Only apply pressure at insensitive points of the housing (edges). Never apply pressure on the display, the
buttons or movable parts of the CX10x0 system.
After successful latching on the top-hat rail the straps should be pushed back to their original position.
2.3 Connecting the Embedded PC to the terminal bus
By reinstalling the once removed terminal the system is connected to the bus.
Finally the wiring must be reinstalled. The removed terminal is reconnected as before. The power supply is
now connected via the UPS-connectors. (see chapter connections for details)
