2.5.1.2 EK1541 - Technical data
Technical data EK1541
Task within the EtherCAT system Coupling of EtherCAT Terminals (ELxxxx) to
100BASE-FX EtherCAT POF networks
Number of EtherCAT Terminals up to 65534 in the overall system
Number of peripheral signals max. 4.2GB addressable IO points
Transmission medium Polymeric Optical Fiber
Cable length between two Bus Couplers max. 50m (100BASE-FX-POF)
Transceiver wavelength 650nm
Laser class 1, see note [}71]
Protocol / Baud rate EtherCAT Device Protocol / 100MBaud
HotConnect max. number of configurable IDs: 4096
Delay typical 1µs
Bus connection 2 x versatile link for POF duplex connector
(connector set ZS1090-0008)
Power supply 24V
DC
(-15%/+20%)
Input current 130mA + (total E-bus current)/4
Current consumption 24 V DC typ. 70mA
E-Bus current consumption -
E-bus power supply (5 V)
depending on ambient temperature
(at higher current consumption the EL9410 power
feed terminal can be used in addition)
max. 2000mA (-25°C ... +55°C)
max. 1000mA (> +55°C)
Power contacts max. 24V
DC
, max. 10A
Electrical isolation 500V (power contact/supply voltage/EtherCAT)
Dimensions (W x H x D) approx. 49mm x 100mm x 70mm
Weight approx. 190g
Permissible ambient temperature range during
operation
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature range during
storage
-40°C ... + 85°C
Permissible relative humidity 95%, no condensation
Mounting [}37]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
cULus [}52]
