HEAD FOOT
1
STOP
2
Set up the adjustable base without the bed frame.
1
Open the box lid.
HEADBOARD
2
Take out all the accessories from the packaging and put them aside. All electronics and compo-
nents that need to be installed are located in boxes under the foundation or attached to the frame.
Before discarding the packing materials, ensure that all the parts are accounted for.
×1
Flat Mattress Retainer Bar
(Exclusively for BEDGEAR Mattresses)
×1
Accessories Box
ACCESSORIES BOX:
×1
AC
Power Cord
×1
Remote
Control
×1
Power Supply with
Battery Backup Box
9V
9V
9V
(Optional)
×3
AAA
Batteries
AAA
×1
Sync Cord
（TXL/T/CKS Only）
×6
Adjustable Legs
Remove the red plastic safety lock before unfolding your adjustable base.
3
Remove the red plastic
safety clip.
Red Plastic
Safety Clip
Remove the folding locking
pin by pulling upward.
Locking Pin
Turn the locking pin 90° in
counter clockwise direction.
Locking Pin
×1(2 for K/CK)
Mattress Retainer Bar
- 3 -
To Next Page
