Beechcraft V35B Bonanza
Pilot Operating Handbook
- 5 -
Section I General
DESCRIPTIVE DATA
ENGINE
The V35B Bonanza is powered by either a Continental E185-1 or E185-8 six cylinder engine rated for a
maximum take-off power of 185 hp at 2300 rpm (max. one minute). The maximum continuous rating is
165 hp at 2050 rpm.
PROPELLER
Beech electrically controlled variable pitch, two blade, 88¬inch diameter propeller with Beech pitch
control motor and spinner. The propeller uses a Beech R203-100 hub with either R201-217-88 or R203-
218-88 blades.
FUEL
Aviation Gasoline 80/87 (red) minimum grade or alternate grades 100LL (blue) or 100/130 (green).
Standard fuel system: Two 20-gallon tanks in wings. Total 34 gallons usable.
Optional fuel system: Two 20 gallon main tanks in wings and either one 10 gallon or one 20 gallon
auxiliary tank installed in the baggage compartment. All of the capacity of the 10 gallon tank is usable.
The 20 gallon tank adds 19 gallons usable fuel to the system.
OIL CAPACITY
The oil capacity is 10 quarts.
WEIGHTS
Maximum Ramp Weight 2660 lbs
Maximum Take-Off Weight 2650 lbs
Maximum Landing Weight 2650 lbs
CABIN DIMENSIONS
Length 6 ft 11 in.
Height 4 ft 2 in,
Width 3 ft 6 in.
Entrance Door 36 in. x 37 in.
BAGGAGE
Volume 16.5 cu ft
Capacity 270 lbs
Baggage Door 22.5 in. x 18.5 in.
