12
6.0 Specifications
UNIdreh 700 UNIdreh LCD/UNIdreh EVU
Phase indication: 3 LED's LCD-Segment L1, L2, L3
Rotary field indication: 2 LED LCD Segments R, L
Voltage range: 70 700 V 3 ; 40700 V ;
Frequency: 15 400 Hz
Operation: continuous operation
Current pick-up: approx. 3 mA approx. 1 mA
Overvoltage class: CAT III, 500 V to ground
Pollution degree: 2
Temperature range: 0 40° C
Protection: IP 40
Test voltage: 2 kV
Dimensions: approx. 124 x 61 x 27 mm
Weight: approx. 200 g approx. 200 g
(UNIdreh EVU approx. 350 g)
5.2 Fuse replacement (UNIdreh EVU only)
The UNIdreh EVU has fixed measuring lines and test probes with
built-in fuses 0,5 A / 500 V, 6 x 32 mm.
The front part of the test probe is screwed together with the
handheld part. The fuse can be taken after solving the bolted joint.
Attention !
Ensure that the fuses are in perfect condition and correctly
positioned in fuse holder.
Fuse 500 mA / 500 V, 56 kA cut-off capacity, 6,3 x 32 mm
Attention !
In order to avoid fire hazard only use the correct fuse with
characteristics regarding type, voltage and cut off as specified in
the instruction manual. The use of auxiliary fuses especially short-
circuiting of fuse holders is strictly forbidden.
