Behncke QWT - Swt 100; SWT 100 Titanium

6
Heat exchanger QWT, WTI, SWT / Technical data
ENGLISH
Item
output Minimum pump capacity Pressure loss
Item no.
kW at 50°
Heating Pool water Heating Pool water
m³/h m³/h kPa kPa
SWT 100-20 22 1.2 10 4.1 5.8 330 004 00
SWT 100-25 38 1.8 10 6.2 6.9 330 006 00
SWT 100-40 46 3.0 10 9.3 5.5 330 008 00
SWT 100-52 67 3.6 12 3.4 9.2 330 010 00
Combo socket 1 ½” x DN 40
For heating the swimming pool water by connecting to a solar power system, heat pump or
alow-temperature heating system.
Consisting of an outer stainless steel jacket with welded-in stainless steel coil, complete with a thermowell
for the installation of an electronic temperature sensor. Including a holder and rubber hose assembly kit.
5.2 SWT 100
Operating pressure: on the heating side: 10 bar
on the pool water side: 3 bar
Item
output Minimum pump capacity Pressure loss
Item no.
kW at 50°
Heating Pool water Heating Pool water
m³/h m³/h kPa kPa
SWT 100-20 22 1.2 10 7.6 5.8 330 004 00 -19
SWT 100-40 46 3.0 10 6.9 5.5 331 008 00 -19
2 sockets 1 ½” (titanium)
For use with water with a high chloride content (unlimited)
For heating the pool water by connecting to a central heating system, complete with a welded thermowell.
Less prone to calcication.
5.3 SWT 100 titanium
Operating pressure: on the heating side: 10 bar
on the pool water side: 3 bar
