Speci cations
Ampli er
Maximum output power* 200 W
Type Class-D
Speaker
Woofer 1 x 8" (200 mm) LF driver
Tweeters 4 x 2.5" (64 mm) MF drivers
Analog Audio Connections
Line in 1 x XLR / ¼ " TRS combo jack, balanced
Impedance 20 k, balanced / 10 k, unbalanced
Line out 1 x XLR, balanced
Impedance 470 , balanced / 220 , unbalanced
Mic 1 / 2 in 2 x ¼ " TRS, balanced
Impedance 10 k, balanced / 4.7 k, unbalanced
Digital Audio Connections
USB Type A
SD / MMC Up to 32 GB supported
File system FAT 16, FAT 32
Format MP3 (DBR & VBR)
Bit rates 32 – 320 kbps
Sample rates 32 kHz, 44.1 kHz, 48 kHz
Bluetooth**
Frequency range 2402 MHz ~ 2480 MHz
Channel number 79
Version Bluetooth spec 4.2 compliant
Output 4 dBm
Compatibility Supports A2DP 1.2 pro les
Maximum communication range 15 m (without interference)
Loudspeaker System Data
Frequency response*** 55 Hz - 17 kHz (-10 dB)
Sound pressure level Max. 106 dB SPL @ 1 m
Limiter Optical
THD+N < 1%
Equalizer
High ±6 dB @ 10 kHz, shelving
Low ±6 dB @ 100 Hz, shelving
Power Supply, Voltage (Fuses)
USA / Canada 120 V~, 60 Hz (T 3.15 A L 250 V)
UK / Australia / Europe 220-240 V~, 50/60 Hz (T 3.15 A L 250 V)
Korea / China 220-240 V~, 50/60 Hz (T 3.15 A L 250 V)
Japan 100 V~, 50/60 Hz (T 3.15 A L 250 V)
Power consumption @ ⁄ max power output 35 W
Mains connection Standard IEC receptacle
Dimension / Weight
Dimensions (H x W x D) 415 x 325 x 1380 mm (16.3 x 12.80 x 54.3")
Weight 13.3 kg (29.3 lbs)
*Independent of limiters and driver protection circuits.
**The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc., and any use of such marks by MUSIC Group is under license.
***Average over stated bandwidth, Measured at 1 meter on axis.
16 17Quick Start GuideC200
