EURORACK MX2642A
10. SPECIFICATIONS
10. SPECIFICATIONS
Input Channels
Mic Input Electronically balanced, discrete input configuration
Mic E.I.N. (22 Hz - 22 kHz) -129.0 dBu, 150 Ohm source
-117.3 dBqp, 150 Ohm source
-132.0 dBu, input shorted
-122.0 dBqp, input shorted
Distortion (THD & N) 0.007% @ +4 dBu, 1 kHz, bandwidth 80 kHz
Gain Range +10 dB to +50 dB
Max Input (Mic) +12 dBu
Line Input Electronically balanced
Gain Range Unity to +40 dB
Max Input (Line) +22 dBu
Channel Fader Range +10 dB to -85 dB
Aux Send Gain Range Off to Unity to +15 dB
Equalization
Hi shelving 12 kHz +/-15 dB, Q fixed at 2 oct.
Hi Mid shelving 3 kHz +/-15 dB, Q fixed at 2 oct.
Mid sweep 100 Hz - 8 kHz +/-15 dB, Q fixed at 1 oct.
Lo Mid shelving 500 Hz +/-15 dB, Q fixed at 2 oct.
Lo shelving 80 Hz +/-15 dB, Q fixed at 2 oct.
Lo Cut (High Pass) filter 75 Hz, 18 dB/oct.
Channel Direct Out
Max Output +22 dBu
Noise @ Unity Gain -94 dBu
Output Impedance 120 Ohm
Channel Insert
Max In / Out +22 dBu
Channel to Channel Crosstalk -95 dB @ 1 kHz
Subgroup Section
Noise Bus noise @ fader 0 dB: -102.5 dBr (ref.: +4 dBu);
-92.5 dBr (ref.: +4 dBu, all channels assigned and set @ Unity Gain)
Submaster Output Max Out +22 dBu balanced/unbalanced
Fader Range +10 dB to -85 dB/off
Main Mix Section
Noise Bus noise @ fader 0 dB: -101.0 dBr (ref.: +4 dBu);
-92.5 dBr (ref.: +4 dBu, all channels assigned and set @ Unity Gain)
Max Output +28 dBu balanced, +22 dBu unbalanced
Aux Returns Gain Range off to Unity to +20 dB
Aux Sends Max Out +22 dBu
General
Distortion (THD & N) 0.007 %, @ +4 dBu, 1 kHz, Bandwidth 80 kHz;
Frequency Response 20 Hz - 40 kHz, +/- 1 dB
any input to any output: 10 Hz -120 kHz +/- 3 dB
Physical
Dimensions (H * W * D) ca. 2 3/8" / 6" (61/152.4 mm) x 17 1/8" / 19" (435.6/482.6 mm) x 14" (355.6 mm)
Net weight 7.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or
shown.
