NOX404 Front Panel
NOX404 Rear Panel
REV button
switches
assignment
of signals at
either side of
crossfader
POWER switch
IEC POWER
socket
Stereo FX LOOP
RETURN jacks
from external FX
device(s) (¼" TRS,
balanced)
USB socket MAIN
OUTPUTS
(RCA)
MAIN
OUTPUTS
(XLR)
MIC input
(¼" TRS,
balanced)
Stereo FX
LOOP SEND
jacks to external
FX device(s)
(¼" TRS,
balanced)
Stereo AUX
OUT jacks (RCA)
Stereo AUX IN
jacks (RCA)
PHONO/LINE
source switch
PHONO
ground
terminal
LINE
INPUTs
(RCA)
PHONO
INPUTs
(RCA)
MODE button
selects
between
XFADE
CURVE A or B
Headphones jack
XFADE CURVE
knob adjusts fade
steepness between
source A and B
NOX1010/NOX606
NOX404/NOX303
NOX202
