39
VIRTUALIZER PRO DSP2024P
8. SPECIFICATIONS
8. SPECIFICATIONS
ANALOG INPUTS
Connectors XLR and 1/4" TRS
Type RF filtered, servo-balanced input stage
Impedance 80 kΩ balanced
Nominal Operating Level -10 dBV or +4 dBu (selectable)
Max. Input Level +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level
ANALOG OUTPUTS
Connectors XLR and 1/4" TRS
Type Electronically servo-balanced output stage
Impedance 80 Ω balanced
Max. Output Level +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level
SYSTEM SPECIFICATIONS
Bandwidth 20 Hz to 20 kHz, +/- 3 dB
SNR 91 dB, unweighted, 20 Hz to 20 kHz
THD 0.018 % typ. @ +4 dBu, 1 kHz, 0 dBu input, gain 1
Crosstalk < -76 dB
MIDI INTERFACE
Type 5-pin DIN-socket IN / OUT / THRU
DIGITAL PROCESSING
Converters 24-bit Sigma-Delta, 64/128-times oversampling
Sampling Rate 46.875 kHz
DISPLAY
Type 4-digit 14 segment alpha-numeric LED-Display
POWER SUPPLY
Voltage USA/Canada
120 V~, 60 Hz
Europe/U.K./Australia
230 V~, 50 Hz
Japan
100 V~, 50 - 60 Hz
General export model
120/230 V~, 50 - 60 Hz
Fuse 100 - 120 V~: T 200 mA H 250 V
200 - 240 V~: T 100 mA L 250 V
Power Consumption 15 Watts max.
Mains Connection Standard IEC receptacle
PHYSICAL
Dimensions (H x W x D) 1 3/4" x 19" x 8" (44 mm x 482,6 mm x 204,4 mm)
Net Weight approx. 4 1/2 lbs (2 kg)
Shipping Weight approx. 6 2/3 lbs (3 kg)
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time
to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
