13 XENYX QX1202USB/QX1002USB User Manual
5. Specications
QX1202USB QX1002USB
Mono Inputs
Microphone Inputs (XENYX Mic Preamp)
Type XLR connector, balanced, discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0Ω source resistance -133 dB / -137 dB A-weighted
@ 50Ω source resistance -130 dB / -134 dB A-weighted
@ 150Ω source resistance -127 dB / -131 dB A-weighted
Frequency response
<10 Hz - 150 kHz (-1 dB)
<10 Hz - 200 kHz (-3 dB)
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB Gain
Impedance 1.9 kΩ balanced
Signal-to-noise ratio 107 dB / 110 dB A-weighted (0 dBu In @ +22 dB Gain)
Distortion (THD + N) 0.006% / 0.005% A-weighted
Line Input
Type ¼" TRS connector, balanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Gain range -10 dB to +40 dB
Max. input level +21 dBu @ 0 dB Gain
Stereo Inputs
Type 2 x ¼" TRS connector, balanced
Impedance
20 kΩ balanced, 10 kΩ unbalanced
(+4 dBu operating level)
20 kΩ balanced, 5 kΩ unbalanced (-10 dBV)
Gain range +4 dBu / -10 dBV
Max. input level +22 dBu
2-Track In
Type RCA connector
Impedance 19.5
Max. input level +21 dBu
Equalizer
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Aux Sends
Type ¼" TRS connector, balanced
Impedance 120 Ω
Max. output level +21 dBu
Aux Returns
Type ¼" TRS connector, balanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Max. input level +21 dBu
Main Outputs
Type ¼" TRS connector, balanced
Impedance 120 Ω balanced
Max. output level +21 dBu
Control Room Output
Type ¼" TRS connector, balanced
Impedance 120 Ω
Max. output level +21 dBu
QX1202USB QX1002USB
Phones Output
Type ¼" TRS connector, unbalanced
Max. output level +21 dBu / 22 Ω (+25 dBm)
2-Track Out
Type RCA connector, unbalanced
Impedance 1 kΩ
Max. output level +21 dBu
Main Mix System Data (Noise)
Main mix @ -∞,
channel fader @ -∞
-105 dB / -108 dB A-weighted
Main mix @ 0dB,
channel fader @ -∞
-93 dB / -96 dB A-weighted
Main mix @ 0dB,
channel fader @ 0dB
-83 dB / -85 dB A-weighted
FX Section
Type KLARK TEKNIK
Converter 24-bit Sigma Delta
Sample rate 40 kHz
Power Supply
Power consumption 20 W
USA/Canada 120 V~, 60 Hz
Adapter MXUL6
Australia 230 - 240 V~, 50 Hz
Adapter MXSAA6
U.K./Europe 230 V~, 50 Hz
Adapter MXUK6 / MXEU6
China/Korea 220 V~, 50 Hz / 220 V~, 60 Hz
Adapter MXCCC6 / MXKR6
Japan 100 V~, 50/60 Hz
Adapter MXJP6
Output 2 x 14.8 V~, 2 x 500 mA
USB
Connecter Type B
Sample rate 48 kHz
Physical/Weight
Dimensions (H x W x D)
50 x 250 x 248 mm
(2.0 x 9.8 x 9.8")
50 x 195 x 248 mm
(2.0 x 7.7 x 9.8")
Weight 1.5 kg (3.3 lbs) 1.1 kg (2.4 lbs)
