XENYX QX1832USB/QX1222USB
QX1832USB QX1222USB
Mono Inputs
Microphone inputs
(XENYX Mic preamp)
6
Type XLR connector, balanced, discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0Ω source resistance -134 dB / -136 dB A-weighted
@ 50Ω source
resistance
-131 dB / -133 dB A-weighted
@ 150Ω source
resistance
-129 dB / -131 dB A-weighted
Frequency response
(-1 dB)
<10 Hz - 150 kHz (-1 dB)
Frequency response
(-3 dB)
<10 Hz - 200 kHz (-3 dB)
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance 2 kΩ balanced
Signal-to-noise ratio
109 dB / 112 dB
A-weighted
(0 dBu In @ +22 dB gain)
107 dB / 110 dB
A-weighted
(0 dBu In @ +22 dB gain)
Distortion (THD+N) 0.005% / 0.004% A-weighted
Phantom power Switchable, +48 V
Line Input
Type ¼" TRS connector, balanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Gain range -10 dB to +40 dB
Max. input level 30 dBu
Frequency Response (Mic In Main Out)
<10Hz - 160kHz ±3 dB
Stereo Inputs
Type
4 x ¼" TRS connector,
balanced
4 x ¼" TRS connector,
unbalanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Gain range -20 dB to +20 dB
Max. input level +22 dBu
2-Track In
Type RCA connector
Impedance 10 kΩ
Max. input level +22 dBu
2-Track In Equalizer 3-band semi-parametric
Low 80 Hz / ±15 dB
Mid
Variable
100 Hz - 8 kHz / ±15 dB
2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Equalizer 4-band Fixed
Low 80 Hz / ±15 dB —
Low mid 500 Hz / ±15 dB —
High mid 3 kHz / ±15 dB —
High 12 kHz / ±15 dB —
Channel Inserts
Type ¼" TRS connector, unbalanced
Max. input level +22 dBu
AUX Sends
Type 2 x ¼" TRS connector, unbalanced
Impedance 120 Ω
Max. output level +22 dBu
QX1832USB QX1222USB
AUX Returns
Type
2 x ¼" TRS connector,
balanced
2 x ¼" TRS connector,
unbalanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Max. input level +22 dBu
Main Outputs
Type XLR, balanced
Impedance 240 Ω balanced, 120 Ω unbalanced
Max. output level +28 dBu
Control Room Output
Type ¼" TRS connector, balanced
Impedance 120 Ω
Max. output level +22 dBu
Phones Output
Type ¼" TRS connector, unbalanced
Impedance 25 Ω
Max. output level +21 dBu / 150 Ω (+25 dBm)
2-Track Out
Type RCA connector
Impedance 1 kΩ
Max. output level +22 dBu
DSP
Type KLARK TEKNIK
Converter
24-bit Sigma-Delta
64/128-times oversampling
Sampling rate 40 kHz
Wireless Input
USB dongle Accepts signals from 2 independent Behringer ULM mics
Main Mix System Data (Noise)
Main mix @ -∞,
channelfader @ -∞
-100 dB / -103 dB
A-weighted
-100 dB / -102 dB
A-weighted
Main mix @ 0dB,
channelfader @ -∞
-88 dB / -91 dB
A-weighted
-86 dB / -88 dB
A-weighted
Main mix @ 0dB,
channelfader @ 0dB
-80 dB / -82 dB
A-weighted
-81 dB / -83 dB
A-weighted
Power Supply
Mains voltage 100 – 240 V~, 50/60 Hz
Power consumption 50 W 40 W
Fuse (100 - 240V~,
50/60Hz)
T 1.6 A H 250 V
Mains connector Standard IEC receptacle
USB
Connector Type B
Audio Stereo in/out
Converter 16-bit
Sample rate 48 kHz
Physical/Weight
Dimensions (W x D x H)
16.9 x 14.6 x 3.5"
430 x 370 x 90 mm
14.6 x 13.3 x 3.5"
370 x 338 x 90 mm
Weight 10.4 lbs / 4.7 kg 8.4 lbs / 3.8 kg
Specications

Behringer XENYX QX1832USB Specifications

General

Brand	Behringer
Model	XENYX QX1832USB
Category	Music Mixer
Language	English
