Firmware upgrade
Beijer Electronics, MA00739 13
5 Firmware upgrade
CAB15 supports firmware upgrades in the field PC download tool. A standard
HyperTerminal with Xmodem support must be used.
The download can be made through the RS232C port on the operator terminal.
Application and bootloader version will be available in the operator terminal
interface.
Perform the following steps to upgrade the CAB15 firmware:
1. Select Setup/Peripherals in the terminal project and add Transparent mode
under the RS232 port.
2. Download the new project to the terminal.
3. Start the Windows program HyperTerminal and enter the following config-
uration: 38400,8,N,1(no flow control).
4. Connect HyperTerminal and press space, to get a menu in the
HyperTerminal and passthrough in the operator terminal.
5. Type D and then Y.
6. Choose Transfer and send file, select the .hms file and set the protocol to
Xmodem; perform these actions quickly. Click Send for CAB15 to update
its software.
7. After the download, the CAB15 firmware is updated. Press X to restart the
adapter.
Port settings for COM1:
Parameter Setting
Bits per second 38400
Data bits 8
Parity None
Stop bits 1
Flow control None
