10 /36 EN

Refrigerator / User Guide

Installation

4.3 Adjustment of the feet

If the product is not in balanced position, adjust the

front adjustable stands by rotating right or left.

In order to adjust the doors vertically,

•Loosenthefixingnutatthebottom

•Screwadjustingnut(CW/CCW)accordingtothe

position of the door

•Tightenthefixingnutforthefinalposition

In order to adjust the doors horizontally,

• Loosen the fixing screw at the bottom

• Loosen the fixing bolt on the top

• Screw the adjusting bolt (CW/CCW) on the side

according to the position of the door

• Tighten the fixing bolt on the top for the final

position

• Tighten the fixing screw at the bottom

Fixing nut

Fixing screw

Sabitleme somunu

Sabitleme vidası

ﬁxing nut

adjusting nut

adjusting bolt

ﬁxing bolt

ayar somunu

ayar civatası

sabitleme

civatası

sabitleme somunu
