Beko WMB 51421 - Installation; Appropriate installation location; Removing the transportation locks; Connecting water supply

58
EN
theproductintoitsplaceafterinstallationor
cleaning procedures.
Appropriate installation location
• Placethemachineonarigidfloor.Donot
placeitonalongpilerugorsimilarsurfaces.
• Totalweightofthewashingmachineandthe
dryer-withfullload-whentheyareplaced
ontopofeachotherreachestoapprox.
180kilograms.Placetheproductonasolid
andflatfloorthathassufficientloadcarrying
capacity!
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductatplaceswhere
temperaturemayfallbelow0ºC.
• Placetheproductatleast1cmawayfromthe
edgesofotherfurniture.
Removing packaging reinforcement
Tiltthemachinebackwardstoremovethe
packagingreinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Removing the transportation locks
A
 Donotremovethetransportationlocksbefore
takingoutthepackagingreinforcement.
A
 Removethetransportationsafetyboltsbefore
operatingthewashingmachine,otherwise,
theproductwillbedamaged.
1. Loosenalltheboltswithaspanneruntilthey
rotatefreely(C).
2. Removetransportationsafetyboltsbyturning
them gently.
3. Attach the plastic covers supplied in the User
Manualbagintotheholesontherearpanel.
(P)
C
 Keepthetransportationsafetyboltsinasafe
placetoreusewhenthewashingmachine
needstobemovedagaininthefuture.
C
 Nevermovetheproductwithoutthe
transportationsafetyboltsproperlyfixedin
place!
Connecting water supply
C
 Thewatersupplypressurerequiredtorun
theproductisbetween1to10bars(0.1–10
MPa).Itisnecessarytohave10–80litersof
waterflowingfromthefullyopentapinone
minute to have your machine run smoothly.
Attachapressurereducingvalveifwater
pressure is higher.
C
 Ifyouaregoingtousethedoublewater-inlet
productasasingle(cold)water-inletunit,you
must install the supplied stopper to the hot
watervalvebeforeoperatingtheproduct.
(Appliesfortheproductssuppliedwithablind
stopper group.)
C
 Ifyouwanttousebothwaterinletsofthe
product,connectthehotwaterhoseafter
removingthestopperandgasketgroupfrom
thehotwatervalve.(Appliesfortheproducts
suppliedwithablindstoppergroup.)
A
 Modelswithasinglewaterinletshouldnot
beconnectedtothehotwatertap.Insuch
acasethelaundrywillgetdamagedorthe
productwillswitchtoprotectionmodeandwill
not operate.
A
 Donotuseoldorusedwaterinlethoseson
thenewproduct.Itmaycausestainsonyour
laundry.
1. Connectthespecialhosessuppliedwiththe
producttothewaterinletsontheproduct.
Redhose(left)(max.90ºC)isforhotwater
inlet,bluehose(right)(max.25ºC)isforcold
waterinlet.
A
 Ensurethatthecoldandhotwater
connectionsaremadecorrectlywhen
installingtheproduct.Otherwise,yourlaundry
willcomeouthotattheendofthewashing
processandwearout.
2. Tightenallhosenutsbyhand.Neverusea
wrenchwhentighteningthenuts.
3. Openthetapscompletelyaftermakingthe
hoseconnectiontocheckforwaterleaksat
theconnectionpoints.Ifanyleaksoccur,turn
offthetapandremovethenut.Retighten
thenutcarefullyaftercheckingtheseal.To
preventwaterleakagesanddamagescaused
bythem,keepthetapsclosedwhenthe
machine is not in use.
Connecting to the drain
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainortothe
washbasin.
A
 Yourhousewillbefloodedifthehosecomes
outofitshousingduringwaterdischarge.
Moreover,thereisriskofscaldingdueto
highwashingtemperatures!Topreventsuch
situationsandtoensuresmoothwaterintake
anddischargeofthemachine,fixtheendof
the discharge hose tightly so that it cannot
