Belarus BELARUS-1523 User Manual (English)

Questions and Answers:

J
Jennifer NelsonAug 19, 2025
Why is there insufficient air pressure in the bottle of my Belarus BELARUS-1523 Tractor?
- M
  mcmahonandrewAug 19, 2025
  If you have insufficient air pressure in the air bottle of your Belarus tractor, it could be due to several reasons. There might be air leakage, which you should eliminate. The pressure regulator operation could be disturbed, requiring you to remove the pressure regulator and send it to the workshop for repair. Alternatively, the suction or pressure valve of the compressor might be faulty, needing cleaning from coke deposits or replacement if excessively worn. Finally, there could be excessive wear or jamming of the compressor piston rings, which would require cleaning from coke deposits or replacement.
J
johnsonrebeccaAug 21, 2025
What to do if the air pressure in the bottle of my Belarus BELARUS-1523 Tractor drops quickly when I brake?
- A
  Andrea CruzAug 21, 2025
  If the air pressure in the bottle of your Belarus tractor drops quickly when you step on the brake pedals, it could be due to a warped, clogged, or damaged inlet valve. In this case, eliminate the warpage, clean or replace the valve. Alternatively, the brake valve diaphragm may be damaged, requiring a replacement.
D
David Torres IVAug 26, 2025
Why is no warm air being fed to the cab of my Belarus Tractor?
- J
  Jason ScottAug 26, 2025
  If no warm air is fed to the cab of your Belarus tractor, it could be due to several reasons. First, there might be no water circulation through the heating unit, so open the tap. Second, ice plugs may have formed in the heater hoses, so break the ice and pass hot water through the hoses. Third, the heater fan may not be operating, so remove the fan fault and check the electric circuit for switching on the fan.
A
Alyssa HuffAug 28, 2025
Why does the pressure in the air bottle of my Belarus Tractor drop quickly when the engine is stopped?
- M
  Michael BriggsAug 28, 2025
  If the pressure in the air bottle of your Belarus tractor drops quickly when the engine is stopped, it is likely due to air leakage through coupling elements of the pneumatic system. Eliminate the leakage to resolve this issue.
D
david02Aug 30, 2025
How to fix alternator noise in my Belarus BELARUS-1523 Tractor?
- S
  Sandra McdonaldAug 30, 2025
  If you are experiencing alternator noise in your Belarus tractor, it may be due to slipping or excessive tension of the alternator drive belt. Remove the alternator and send it to the workshop for repair. Adjust the tension of the alternator drive belt.
B
Bryan GarciaSep 1, 2025
Why is the air passed to the cab of my Belarus BELARUS-1523 so humid?
- N
  nmooreSep 1, 2025
  If the air passed to the cab of your Belarus tractor has high humidity, it could be due to water leakage in the heater radiator. In this case, eliminate the leakage or replace the radiator. It could also be due to water leakage in the connections of the heater system, so tighten the buckles.
P
pcopelandSep 3, 2025
What to do if the electromagnetic clutch of the compressor fails to operate in my Belarus BELARUS-1523?
- M
  Maria BrandtSep 3, 2025
  If the electromagnetic clutch of the compressor in your Belarus tractor fails to operate, and you don't hear a metallic click when turning the temperature regulator, it could be due to electric equipment failure. Check the operability of the block of pressure sensors by means of a tester or multimeter; the leads of the block of sensors (red and pink wires) shall be rung out between one another. Also, check the intactness of the connections of the electric circuits from the compressor coupling to the air conditioner control panel.
L
Luke MercadoSep 5, 2025
Why does the air conditioner fan motor in my Belarus BELARUS-1523 Tractor fail to operate?
- F
  Francisco LevineSep 5, 2025
  If the air conditioner fan motor fails to operate in your Belarus tractor, it is likely due to an electric equipment fault. Check the intactness of the respective fuse (25 ?, see electric diagram) on the fuse block located in the dashboard. Replace the blown out fuses by new ones. Check the presence of supply voltage at the air conditioner motor M7 by means of a test lamp when the switch is set to the ON position and the battery is connected. If the electric circuits are intact, but no supply voltage is present at the motor ?7, replace the switch.
R
Rhonda LinSep 7, 2025
Why are the trailer’s brakes ineffective when using my Belarus Tractor?
- J
  Jared StephensSep 7, 2025
  If the trailer’s brakes are ineffective when using your Belarus tractor, it could be because the brake valve fails to maintain the pressure in the control mainline at the level of 0.77...0.80 MPa (7.7...8.0 kgf/cm2). You can adjust the brake valve and its actuator. Alternatively, the brake valve might fail to drop the pressure in the coupling mainline to zero, so adjust the brake valve and its actuator.
M
millertimothySep 10, 2025
What to do if the solenoid valve of the engine start assisting facilities does not operate on my Belarus BELARUS-1523 Tractor?
- G
  Glenn AndersonSep 10, 2025
  If the solenoid valve of the engine start assisting facilities does not operate on your Belarus tractor, check the circuit and tighten the wire fastening contacts.

Belarus BELARUS-1523 Specifications

General

Engine Type	Diesel
Cylinders	6
Maximum Pressure	20 MPa
Ground Clearance	470 mm
Engine Power (kW)	110 kW
Transmission	Mechanical

Summary

TO THE OPERATORS’ ATTENTION

INTERNATIONAL SYMBOLS

Standard symbols used for instruments and controls, providing visual identification for operation.

SAFETY REQUIREMENTS

Essential safety guidelines covering general operation, transportation, maintenance, fire prevention, and hygiene.

BRIEF DESCRIPTION

Serial Numbers of Tractor Components

Information on the location and identification of tractor and engine serial numbers.

TECHNICAL DATA

ENGINE

Detailed technical specifications and characteristics of the tractor's engine.

DRIVE CONTROLS AND INSTRUMENTATION

Instrument Cluster

Description of gauges, indicators, and warning lamps within the instrument cluster.

Combined indicator

Explanation of the combined indicator's display and function for monitoring tractor systems.

Safety Fuse Blocks

Location and rating of safety fuses that protect electrical circuits from overload.

BELARUS 1523/1523В Gear-shift lever (27), Range selector lever (28)

Identification and diagrams for the gear-shift and range selector levers.

Control panel of the differential lock, FDA and front PTO shaft (32)

Description of the control panel for differential lock, FDA, and front PTO.

Hydraulic Distributor Control Levers (33а, 33b, 33c)

Explanation of the control levers for the hydraulic distributor system.

PTO Independent/Synchronous Change-Over Handle (35)

Operation of the handle for switching between PTO drive modes.

TRACTOR REVERSIBLE OPERATION POST (BELARUS 1523В/1523В.3)

Controls of the Reversible Operation post

Details on additional controls for the reversible operation post.

BELARUS Seat

Instructions for adjusting the tractor seat for operator comfort and safety.

CONSTRUCTION AND OPERATION OF TRACTOR COMPONENTS

ENGINE

Detailed construction and operation of the engine and its main components.

Clutch

Description of the clutch mechanism, assembly, and adjustment procedures.

GEARBOX

Construction and operation of the gearbox, including its control mechanisms.

REAR AXLE

Construction and operation of the rear axle, differential, and final drives.

REAR POWER TAKE-OFF SHAFT (PTO)

Description of the rear PTO shaft, its drive, and tail-pieces.

FRONT PTO (if installed)

Construction and operation of the optional front PTO system.

FDA drive

Details on the construction and operation of the front driving axle drive.

Wheel reduction gears

Description of the planetary spur-gear type wheel reduction gears.

BRAKES

Explanation of the tractor's service and parking brake systems, their actuation, and maintenance.

PNEUMATIC ACTUATOR OF THE TRAILER BRAKES

Description of the pneumatic brake actuator for trailers.

HYDROSTATIC POWER STEERING

Design and operation of the hydrostatic power steering system.

RHL Electronic Control System

Explanation of the electronic control system for the rear hitch linkage.

REAR HITCH LINKAGE (RHL)

Construction and operation of the rear hitch linkage and its control components.

AIR CONDITIONING AND CAB HEATING SYSTEM

Operation and control of the cab's climate control system for heating and cooling.

TROUBLESHOOTING

ENGINE

Troubleshooting steps for engine starting, power, exhaust, and overheating issues.

Clutch

Troubleshooting for clutch torque transmission, engagement, and noise problems.

Brakes

Troubleshooting for brake inefficiency, incomplete release, and non-uniform operation.

Steering control

Troubleshooting for excessive steering force, wheel rotation issues, and oil leaks.

Hydraulic Lift Linkage

Troubleshooting for the hydraulic lift linkage not moving or moving slowly.

SCHEDULED MAINTENANCE

SCHEDULED MAINTENANCE CHART*

Table outlining required maintenance operations and their recommended intervals.

Sequence of the Maintenance Operations

Step-by-step procedures for performing daily and periodic tractor maintenance.

EVERY 1000 HOURS OF OPERATION

Major maintenance procedures required after every 1000 hours of tractor operation.

Procedure 46. Changing Oil in the Transmission Housing, Procedure 47. Changing Oil in the HPS Oil Tank, Procedure 6. Checking the Brake Liquid Level in the Master Cylinder Tanks of the Hydraulic Actuator of the Clutch and Service Brakes

Procedures for checking and changing oil and brake fluid levels in various systems.

APPENDICES

ADJUSTING PARAMETERS OF THE Д-260.1/Д-260.1S2 ENGINE

Key adjustment parameters and specifications for the tractor's engine.

RECOMMENDED FUELS, OILS, LUBRICANTS, AND FLUIDS AND THEIR EQUIVALENTS

List of recommended fuels, oils, lubricants, and fluids with their specifications and change intervals.

Electric Connection Diagram of the LD, FDA and GB Reduction Gear Control Systems

Wiring diagrams for the tractor's electronic control systems.
