N40067 - 7/11 - Subject to change. © Belimo Aircontrols (USA), Inc.
Actuators: ZONE 24NC ZONE24NO ZONE24NC-S ZONE24NO-S ZONE120NC ZONE120NO
ZONE120NC-S ZONE120NO-S
TO AUXILIARY
CIRCUIT
Red
Red
MOTOR
T-S TAT
L1(HOT)
L2
24 120/230
Motor Lead Color Black Black
Built-in Auxiliary Switch (optional) (-S models)
Wiring for Control Valves
On/Off, 24V, 120V
