Installation Instructions
Non-direct Mounting Methods
KH-AF Non-direct mounting with ZG-108 mounting bracket
Non-direct mounting using various accessories
KH-AF crankarm including retaining ring. Caution: the
retaining clip supplied with the clamp is not used to mount the
KH-AF crankarm.The KH-AF (-1) crankarm is used in non-
direct coupled mounting applications.
Two sizes are available:
KH-AF For round shafts up to 3/4” or square shafts up to 5/8”
KH-AF-1 For jackshafts up to 1.05”
ZG-AF US
Linkage
Kit
KH-AF
Crankarm
ZG-106 or
ZG-107
DC1
Damper Clip
Dimensions [All numbers in brackets are in millimeters.]
To Next Page
