TTF
TTF Series Spring Return Direct Coupled Actuator
● Easy-to-adjust mechanical stop to limit damper rotation.
● Cut labor costs with simple direct coupling. actuator
centers on 1/2” shaft.
● Clockwise or counterclockwise fail-safe mounting
for fail-safe.
● Compact size with the shortest shaft-center to edge
distance in the industry - 0.77”.
● True mechanical spring return – the most reliable fail-safe.
● Check damper position easily with clear position indicator.
● Don’t worry about actuator burn-out.
It is overload-proof throughout rotation.
● Need to change control direction?
Do it easily with a simple switch (modulating actuators).
● Built-in auxiliary switch is easy to use, offers feedback
or signal for additional device.
● Microprocessor-controlled brushless DC motor increases
actuator life span and reliability, provides constant running
time (modulating actuators).
● Rugged housing withstands rough handling in the
mechanical room.
● 3 ft. standard cable and conduit connector (not shown)
eases installation.
A CLOSER LOOK…
The Trane Difference
● Low Installation and Life-Cycle Cost.
Easy installation. Accuracy and repeatability.
Low power consumption. No maintenance.
●
Long Service Life.
Components tested before assembly. Every product tested before shipment.
30 years direct coupled actuator design.
©
