Secure DVI-I KVM Dual-Head Switch with Audio User Manual
SECTIONS
Table of Contents
1 3 4 5 6 87
OVERVIEW
2
Specifications
Part No. F1DN104E-3, F1DN104F-3
Enclosure Metal enclosure with high-impact plastic
faceplate
Power Requirements 12V DC, 1.5A (minimum) power adapter with
center-pin-positive polarity
AC Input 100 to 240VAC
No. of Secure Channels 4
No. of Users Supported 1
No. of Computers Supported 4
Monitors Supported 2 single-link and dual-link digital DVI-D
displays; VGA & HDMI monitors with
compatible cables
Max Resolution Support 3840x2160 pixels (UHD 4K) at 30Hz,
2560x1600 pixels @ 60Hz
Console Keyboard Input USB Type A or PS/2 Mini-DIN 6-pin female
connector
Console Mouse Input USB Type A or PS/2 Mini-DIN 6-pin female
connector
Console CAC Input USB Type A (F1DN104F-3 model only)
Console Monitor Port 2 DVI-I dual-link female
Console Speaker 1/8" (3.5mm) female
CPU Keyboard/Mouse Ports USB Type B
CPU CAC Ports USB Type B (F1DN104F-3 model only)
CPU Keyboard/Mouse Ports USB Type B
CPU Audio 1/8" (3.5mm) female
CPU Monitor Ports 2 DVI dual-link female
Port Selectors 4
LED Indicators 4
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
Dimensions (F1DN104E-3) 12.5 (W) x 6.4 (D) x 2.5 (H) in
(F1DN104F-3) 12.5 (W) x 6.4 (D) x 2.5 (H) in
Weight (F1DN104E-3) 4.85 lbs.
(F1DN104F-3) 4.9 lbs.
Made in Designed in California. Assembled in US with
US and Foreign components.
Product Life-Cycle 5 years
Warranty 3 years
Security Accreditation
Common Criteria Validated To Niap
Protection Profile PSS Ver. 3.0
