USB INSTALLATION
19
USB INSTALLATION
18
COMPUTER:
5. Using a standard USB A-to-B cable (we recommend Belkin Part#
F3U134-XX or F3U134-XX-GLD), insert the end with the B-type
connector to the SOHO Series KVM Switch. Insert the other end of
the cable with the A-type connector to an available port on your
USB computer or USB hub that is attached to your computer. See
fig. 12.
6. Your computer should recognize your KVM Switch and will
automatically install the HID USB driver if not already installed on
your computer.
Audio and Microphone Connections are not required to use with
your KVM Switch.
(Recommend to use Belkin PRO Series Audio Cables
Part# F8V209-XX)
CONSOLE:
7. Using the audio cable attached to your speakers, connect the male
3.5mm plug to the SPEAKER IN on the CONSOLE of your SOHO
Series KVM Switch. See fig. 13.
8. Using the mic cable attached to your microphone, connect the
male 3.5mm plug to the MIC IN on the CONSOLE of your SOHO
Series KVM Switch. See fig. 13.
fig. 12
fig. 13
