Bella 550 BR - Location of the Equipment

1. Fueltank 105 L
2. Battery
3. Suction head of manual
bilgepump
4. Thru hull fitting of
bilgepump
5. Fuel filter
* OPTIONAL
Fuel
105 L
1
-
+
2
3
4
5
3.
4.
5.
28
550 BR
22. Location of the equipment
The locations of the equipment can vary depending on the accessories installed.
