OPERATIONS AND MAINTENANCE PROCEDURES
CONVEYOR TOASTER MODEL – JT1 & JT1-B
WARNING – NEVER SPRAY YOUR TOASTER WITH WATER. NEVER
SUBMERGE INTO WATER.
Daily – 1) Clean the air intake area under the toaster with a slightly dampened cloth.
2) Wipe the conveyor surface and exterior surfaces.
3) Remove and wash the Crumb Tray and then replace the Crumb Tray.
Weekly - 1) Clean the air intake area under the toaster with a slightly dampened cloth.
2) Turn the Conveyor Speed Control to fastest setting (100).
a. For lightly soiled conveyors belts, wipe with a damp cloth.
b. For heavily soiled conveyor belts, wipe with a light abrasive pad.
NEVER OPERATE YOUR TOASTER WITHOUT THE CRUMB TRAY IN PLACE
AS THIS MAY CAUSE OVERHEATING IN AND AROUND THE CONTROLS AND
MOTORS.
GENERAL MAINTENANCE
1. REPLACING HEATER TUBES (Tip – replace only one tube at a time to prevent
confusion when re-wiring)
a. DISCONNECT TOASTER FROM POWER SOURCE.
b. Remove both side panels.
c. Disconnect heater tube wires from the terminal blocks.
d. Lift the heater tube retainer by loosening the screw and sliding the retainer up so
that the holes line up.
e. Gently pull the tube to be replaced out of the toaster.
f. Gently slide the replacement tube into the toaster.
g. Slide the retainer back down and tighten the screw.
2. REPLACING FAN MOTOR (Tip – make note of which side the label on the fan motor is
prior to removal)
a. DISCONNECT TOASTER FROM POWER SOURCE.
b. Remove the rear cover.
c. Unplug the fan motor power supply cord.
d. Remove the (4) screws (and grill) that hold the fan motor in place.
e. Put the replacement fan motor and grill in place. Using the same (4) screws secure
in place in the same manner as removed.
f. Reconnect the fan motor power cord.
g. Replace panels and test under power.
