Installa tion of aesth etic panel
【 】Figure4a
2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of
dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by
screws and bolts(See figure 4b) .
Ins tallation of a esthe tic
wood en pan el
【 】Figure4b
. take awa y the four
short screws
. pin up the four long
screws
1
2
20
