Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do
not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1.Select a level surface that
provides enough open
space for the intake and/or
outlet vents.
(1) The minimum installation
height is 85cm above floor
level.
(2) The rear surface of
appliance must be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, and
a
minimum clearance of
20cm is required between the
oven and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/or
outlet openings can damage
the oven.
(5) Place the oven as far
away from radios and TVs
as possible. Operation of
the
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over a range cooktop
or other heat-producing
appliance. If installed near
or over a heat source, the
oven could be damaged
and the warranty would be
void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
