• The hose should be attached to a
height of at least 40 cm, and 100 cm
at most.
• In case the hose is elevated after
laying it on the floor level or close
to the ground (less than 40 cm
above the ground), water discharge
becomes more difficult and the
laundry may come out excessively
wet. Therefore, follow the heights
described in the figure.
• To prevent flowing of dirty water back
into the machine and to allow for easy
discharge, do not immerse the hose
end into the dirty water or drive it in
the drain more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short,
use it by adding an original extension
hose. Length of the hose may not
be longer than 3.2 m. To avoid water
leak failures, the connection between
the extension hose and the drain
hose of the product must be fitted
well with an appropriate clamp as not
to come off and leak.
Adjusting the feet
A
In order to ensure that the product
operates more silent and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet. Otherwise, the
product may move from its place
and cause crushing and vibration
problems.
1. Loosen the lock nuts on the feet by
hand.
2. Adjust the feet until the product
stands level and balanced.
3. Tighten all lock nuts again by hand.
A
Do not use any tools to loosen the
lock nuts. Otherwise, they will get
damaged.
Raising the appliance
In order to raise the appliance to eliminate
the gap below the worktop, you will need
to order special optional kit.
Built-in installation section.
Without optional
raising feet.
Gap
With optional raising
feet. Minimum
height=55 mm, max
height=65mm
Service Ref. No. 1493
