9
CHAPTER 5
SETTING UP INSTALLATION
Move the machine near its permanent position without the
packaging base.
Cut tube-holding straps.
Remove the 3 fixing screws marked (A) and remove the 3
spacers marked (B)
Remove the screw (C).
A spacer will fall inside the machine.
By tilting the machine, remove the above mentioned spacer.
Stop the holes using the plugs that you will find inside the
bag containing the instruction booklet.
WARNING:
DO NOT LEAVE THE PACKAGING IN THE REACH OF
CHILDREN AS IT IS A POTENTIAL SOURCE OF DANGER.
8
CHAPTER 4
MAXIMUM WASH LOAD DRY
POWER INPUT
ENERGY CONSUMPTION (PROG. 90°C)
FUSE RATING
SPIN
WATER PRESSURE
SUPPLY VOLTAGE
TECHNICAL DATA
kg
2150
1,8
13
230
W
kWh
A
MPa
V
82 cm
60 cm
54 cm
64
1400
DRYING
r.p.m.
WASHING
min. 0,05
max. 0,8
