DIAGRAM 11
Step 9 Diagram 10
TO TAKE OFF THE DROPSIDE FROM CRIB
From the crib side where yu want to take off
the dropside:
loosen the screws E with wrench B of only one
headboard. Do not take off the screws com-
pletely.
Step 10 Diagram 11
Pull the leg of this headboard towards outside
(1). Catch th dropside at the bottom (2) and let
the pin of screw Y goes out from dropside
mechanism.
Step 11 Diagram 12
Lift up the dropside (3) and let the screw X
goes out from dropside mechanism.
Take off the dropside (4).
Tighten again the screw E with the wrench B
(5).
DIAGRAM 10
