Bellman BE1341 - Testing; How to Test

Testing
ItiseasytotesttheBellmanAlarmClock,BE1341.IftheAlarmClockdoesnotworkas
describedbelow,youcancheckfurtherunderTroubleshootingguide.
How to test
TheBE1341BellmanAlarmClockshouldalwaysbeconnectedtotheelectricsocketwith
theenclosedpowersupplyunit.
Totesttheashinglight,soundandvibrationwiththeBE1270BellmanBed-shaker
(accessory):
• SwitchonthealarmwiththeAlarmDial(5)byturningittoposition1
• TurntheAlarmPointeranticlockwiseusingtheAlarmCallKnob(10)untilthe
alarmontheclockisactivated.
• TheBellmanAlarmClockwillgivethefollowingindications:
o Switchingonclockfacebackgroundillumination(3).
o Flashingwiththeashinglights(17)onthefront,providedthattheFlash
Switch(9)isintheONposition.
o Emittingasoundsignal,providedthatthesoundswitch(7)isintheON
position.
o ABE1270BellmanBed-shaker(accessory)willvibrateifconnected
Twotestsarerequiredtocarryoutafulltestoftheexternaltrigger;onetotestcontactand
anothertotestvoltage.ForfurtherinformationseeActivation.Pleasenotethatwhenthe
SnoozeButton(4)ispressedduringanalarmfromanexternaltrigger,anyfurtheralarm
viatheexternaltriggerwillbeignoredfor45seconds.
• Connectthealarmunittotheexternaltriggerinput(13).
• Activatethealarm.
• TheBellmanAlarmClockwillgivethefollowingindications:
o Flashingwiththeashinglights(17)onthefront,providedthattheFlash
Switch(9)isintheONposition.
o Emittingthesoundsignalselectedviatheexternaltriggersignalswitch(8),
providedthattheSoundSwitch(7)isintheONposition.
o IftheBE1270BellmanBedShaker(accessory)isconnected,itwillvibratein
thewayselectedviatheexternaltriggersignalswitch(13).
Totestthebuilt-intelephoneconnection:
• Connectinput(15)ontheBellmanAlarmClocktoananaloguetelephonesocket
usingaBE9105telephoneex(accessory)andanadapterplug(accessory).
• Ringthetelephonenumber
• TheBellmanAlarmClockwillgivethefollowingindications:
o Flashingwiththeashinglights(17)onthefront,providedthattheFlash
Switch(9)isintheONposition.
o Emittingaring-typesoundsignal,providedthattheSoundSwitch(7)isinthe
ONposition.
o TheBE1270BellmanBedVibrator(accessory)willvibrateifconnected
