Servo Control and
Data Interfac
e
133:136 O To monitor servo status (FLAG[3:0]).
177 I Spindle hall sensor input (FGIN).
178 I Sledge photo interrupt signal input (PHOI).
179 O Chip selection signal to RF chip (serial data enable) (SCSJ).
180 I/O Data signal from/to RF chip (SDATA).
181 O Serial clock source to RF chip (SCLK)
.
182 I Defect flag input signal (DFCT).
183 O Laser diode on/off control output (LDC).
184 O Spindle power driver on/off control output (SPDON).
187-189, 191
O
General-purpose open collector output used
for servo control (GPIO9-7, 5);
Pull up to VCC using a 4.7-k&! resistor
.
190, 192 I/O
General-purpose input/output used for servo control (GPIO6, 4);
(5V tolerant input).
Servo DVD-RAM
Interface
128 O DVD-RAM wobble detector circuit clock source to preamp (WBLCLK).
129 O DVD-RAM wobble output (WBL).
130 O DVD-RAM land/groove flag (LG).
131 I DVD-RAM header position index 2 (IP2).
132 I DVD-RAM header position index 1 (IP1).
System Memory
Interface
5:8,
11:17, 20 O DRAM address bus (DMA[11:0]).
21 O Memory column address strobe output (DCAS#).
22, 23
O DRAM chip select outputs (DCS[1:0]#).
24, 25, 28 O Memory row address strobe output (DRAS[2:0]#).
29 O Memory output enable (DOE#).
30 O Memory write enable output (DWE#).
31:33, 36:42,
45:50
I/O Memory data bus (DB[15:0]).
51 O Output clock to DRAM (DSCK).
54 O Memory data I/O mask output (DQM).
Video DAC Interface
109 O CVBS/chroma signal (FDAC) for simultaneous mode
.
110 O Composite component signal (VDAC) for YUV mode.
113 O Luma component signal (YDAC) for YUV mode and Y/C processing
.
114 O Chrominance component signal (CDAC) for Y/C processing.
115 O Chrominance component signal (UDAC) for YUV mode
.
ES6688A Device Interfaces (Continued
)
Name
Pin Numbers I/O Definition
