2.2 Do not adjust any screws in the Mechanism Block except for “Tilt Adjust Screws”, as they are
adjusted precisely at the factory.
2.3 Replacement of the Pickup Block is impossible. Always replace the Traverse Ass’y when the
Pickup Block needed to be replaced. Do not touch the lens or lens holder of the Pickup Block.
2.4 The Guide Rails of the Pickup Block are greased. Take care when handing.
2.5 When you try to slide the Pickup Block, do not press or pull it directly. Always turn the dive gears
with your fingers.
2.6 Be sure that the anti-slipping rubber on the turntable or clean. If there is dust or it is greasy, clean
the part with the liquid that contains 50% each of alcohol and water.
When removing the Mechanism P.C.B. Ass’y, you need to short-circuit the laser diode shorting
lands beforehand.
Test Equipment / Jigs
Variable isolating transfomer, Dual channel oscilloscope, Digital multimeter
Specification
1 Chassis
Laser concept 2 laser for DVD and VCD
2 Disc formats
DVD+R Yes
DVD-R Yes
DVD+RW Yes
DVD-RW Yes
CD-R Yes
CD-RW Yes
3 Media formats
DVD-Video Yes
Audio CD Yes
Video CD
VCD 1.0,1.1,2.0
S-Video CD Yes
CD-ROM DivX,MPEG4,MP3, JPEG, Kodak Picture CD,WMA
4 Player features
Parental control Yes, numerical lock
Screen saver Yes
Picture mode select Yes
Video strobe Yes
Video filter Yes
File browser DivX, MP3, JPEG, Kodak Picture CD,WMA
5 Player functions
Play/stop/pause Yes/Yes/Yes
