12 13
INSTALLATION
GUIDE (CONTINUED)
INSTALLATION INSTALLATION
Connecting Hot & Cold Supply Lines
Connect the hot & cold supply lines onto the matching water
valves and secure the connection with an adjustable wrench.
Battery Box
Secure the battery bracket by using 3M adhesive or screws.
Insert 4 AA batteries into the battery pack, and place the battery pack into the
battery bracket. Connect the data cables and secure them hand tight. When
completed, turn the hot & cold water lines back on.
6.85 in
OR
9.8 in
*Recommended Placement
To Next Page
