POP-UP DRAIN
INSTALLATION
DRAIN INSTALLATION DRAIN INSTALLATION
NOTE: The pop-up drain
is fully assembled in the
box. Disassemble the
pop-up drain so that each
component is separate
before installing.
After removing the existing drain
from your sink, follow the instructions
below to install the pop-up drain.
1. Insert the drain tube
through the sink.
2. Slide the washer and cone
washer up the drain tube
from beneath the sink.
3. Secure the drain tube
to the sink using the nut.
4. Press the drain into
the drain tube.
5. Connect the drain tube
to the bathroom plumbing.
This process may vary
depending on the sink and
plumbing of your home. Some
methods include threaded
connections, while others
use compression fittings.
Drain
Drain
tube
Washer
Cone
Washer
Nut
