1/2" DRIVE IMPACT WRENCH
14
PARTS LIST
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the
½" impact wrench.
Any attempt to repair or replace electrical parts on this impact wrench may create
a safety hazard unless repairs are performed by a qualified technician.
For more information, call the Toll-free Helpline at 1-866-349-8665, Monday –
Friday from 9am to 5pm Eastern Standard Time.
Always order by key number.
Key # Part # Part Name Quantity
1 4030090005 ST4.9X50 4
2 4040030003 5MM SPRING WASHER 4
3 4040010011 5MM WASHER 4
4 3140100013 RUBBER SLEEVE 1
5 2020050079 ALUMINUM SHELL 1
6 3140020017 0 TYPE SEALING RING 1
7 2010080084 SHAFT COAT 1
8 2030020034 WASHER 1 1
9 2040040131 OUTER SHAFT (FI MACHINING) 1
10 4080080002
BALL
6.35mm
2
11 2040200014 IMPACT BLOCK (FI MACHINING) 1
12 4080060001
BALL
5MM
24
13 2030020351 WASHER 2 1
14 2050060240 TORQUE SPRING 1
15 2040040113 PINNER SHAFT 1
16 2010010132 PLANETARY 3
17 4110010011 PIN 3
18 2030020229 WASHER 3 1
19 4010010084 BEARING 6002 2RS 1
20 4100010015 CIRCLIP 1
21 2010090082 INNER GEAR RING 1
22 3140020132 OIL SEAL RING 1
23 2020020050 GEAR BOX 1
24 3190010023 WOOL FELT SEAL RING 1
25 4010010055 BEARING 6001 2RS 1
26 1010180014 ROTATOR 1
27 4010010048 BEARING 608 RS 1
28 3140040014 BEARING COVER 1
