15
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the push
reel lawn mower.
For more information, call the Toll-free Helpline, at 1-866-349-8665 Monday - Friday
from 9am to 5pm Eastern Standard Time.
Always order by PART NUMBER, not by key number.
PARTS LIST
QuantityPart NameKey # Part #
1 101046130000-01 Push handle assembly 1
GB/T12 M6x35 Semi-round head bolt 6
101046052001-01 Connection handle 2
105002053001-01 Tool handle 1
101019120000-01 Rhomb knob assembly 6
101015033006-01 Rear wheel pull lever 1
GB/T6172.2-M8 Insert nut 2
23011708122-01 Washer 6
101015032006-01 Straight blade positioning rod 1
GB/T70.2 M8x16 Hexagon socket flat round head bolt 2
113001100003-01 Rear wheel support assembly 2
101051150000-01 Left handle adjustable height assembly 1
101057023000-01 Rear wheel 2
23012013102-01 Washer 4
GB/T894.1-12 Snap ring 2
GB955-12 Wave spring washer 2
21040820242-01 High steps bolt 2
101027090001-01 Finished straight blade 1
101030058003-01 Square adjustable blade nut 2
26117040442-01 Adjustable blade spring 2
GB/T 93 8 Spring washer 4
21030820652-01 Adjustable blade pull lever 2
101043055001-01 Left connection plate 1
101047024057-01 Wheel cover 2
GB/T894.1-19 Shaft snap ring 2
23013420082-01 Wheel shaft tube adjustable washer 2
101044030057-01 Big wheel assembly 2
101045050001-01 Left support plate assembly 1
23012011152-01 Wheel shaft adjustable washer 2
GB/T6172.2-M10 Insert nut M10 2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
