PARTS LIST
Carefully remove the tiller from its packaging and check that the following parts are
included:
A. Tiller 1pc J. Nut M8 4pcs
B. Upper handle assembly 1pc K. Bolt M8 x 20 4pcs
C. Front guard 1pc L. Pin 1pc
D. Depth regulator bar 1pc M. Wheel lock pin 2pcs
E. Tire 2pcs N. Nut M10 2pcs
F. Manual 2pcs O. Bolt M10 x 25 2pcs
G. Bottle of engine oil 1pc P. Wrench 2pcs
H. Bolt M8 x 50 4pcs Q. Cable tie 1pc
I. Handle knob 4pcs
C
E
D
FG
J
K
H
LPQ MO N
I
A
B
WARNING
If any parts are damaged or missing, do not operate this tiller until the missing parts
are replaced. Failure to heed this warning could result in serious personal injury.
NOTICE
Always recycle the packaging in accordance with local recycling programs.
