6) For safe operation, never use the engine with either worn or damaged parts. Parts
should be replaced and not repaired. Use genuine spare parts. Parts that are not
of the same quality can damage the engine and impair your safety.
3. COMPONENTS AND CONTROLS
3.1 ENGINE COMPONENTS
1. Oil filler cap with dipstick
2. Oil drain plug
3. Air cleaner cover
4. Fuel shut off valve
5. Spark plug cap
6. Engine code
Note your engine serial number here: _____________________________
3.2 ACCELERATOR CONTROL
The throttle trigger (generally a lever), fitted to the machine, is connected to the
engine by a cable.
Consult the machine’s Instructions Manual to identify the throttle trigger and its
positions, usually marked by symbols, corresponding to:
CHOKE = to be used for starting from cold.
FAST = corresponds to maximum revs; to be used when working.
SLOW = corresponds to minimum revs.
