9 TON ELECTRIC LOG SPLITTER
14
PARTS LIST
WARNING:
When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the log splitter.
Any attempt to repair or replace electrical parts on this log splitter may create a
safety hazard unless repairs are performed by a qualified technician.
Customer Service / Tech Support 1-866-206-0888.
Key# Part # Description Qty
1 5240-547-1 Nut 4
2 5240-547-2 Circlip 22 1
3 5240-547-3 Flat Washer, M10 6
4 5240-547-4 Valve Cord 1
5 5240-547-5 O-Ring 8.75x1.8 1
6 5240-547-6 Valve Retract Spring 1
7 5240-547-7 O-Ring 11.2x2.65 3
8 5240-547-8 Spring 1
9 5240-547-9 Safety Valve Core 1
10 5240-547-10 Aluminum Cover (Rear) 1
11 5240-547-11 Safety Valve Core 1
12 5240-547-12 O-Ring 10.6x1.8 1
13 5240-547-13 Safety Valve Sleeve Adjusting Spring 1
14 5240-547-14 Adjusting Spring Basis 1
15 5240-547-15 Stud 4
16 5240-547-16 Cylinder 1
17 5240-547-17 Piston 1
18 5240-547-18 Seal 70 1
19 5240-547-19 O-Ring 35.5x3.55 1
20 5240-547-20 Spring 1
21 5240-547-21 Circlip 40 1
22 5240-547-22 Snap Washer 1
23 5240-547-23 O-Ring 38.7 x 2.65 1
24 5240-547-24 O-Ring 64.4x3.1 1
25 5240-547-25 O-Ring 7x1.9 2
26 5240-547-26 Bleed Screw M5x12 1
27 5240-547-27 Wear-Resisting Belt 127x4x2 1
28 5240-547-28 O-Ring 40 1
29 5240-547-29 Piston Rod Seal 40 1
